New rural solar street light installation precautions

Views: 1     Author: 路灯采购网     Publish Time: 2019-10-16      Origin: Site

1. Site selection: Since the solar street lamp is powered by absorbed solar energy, the installation and location of the solar street lamp is very important. The street lamp must be installed in a place with sufficient light and long exposure time, and there should be no big trees nearby. Or building blockage will affect the normal operation of solar street lights.


2, the direction of the solar street light panel: solar street light battery board is an important component of solar street light, its orientation is also very important, not just what direction is possible. The front of the solar panel avoids no obstacles and needs to be adjusted to the south. The best orientation is actually that the solar panel is at a 90° vertical angle to the sunlight, which is most conducive to battery charging.


3. Waterproof installation of solar battery: Since the street lamp is directly exposed, it is necessary to make waterproof measures. The battery waterproof of the street lamp is realized by the battery buried box. It uses the special threading pipe and battery for solar energy. The boxes are sealed and connected, which is a good waterproof rental. However, the interface between the two must be firmly connected to avoid water ingress.


4. Installation and commissioning of the line: After the installation is completed, it is necessary to debug the solar street light. If there is no problem, it is considered to be completely installed. First, you need to connect the positive and negative terminals of the battery to the two terminals of the solar street light controller, and then connect the two wires of the solar panel and the led street lamp. After the connection, you can touch the adjustment button of the controller. To test mode 19, if the solar street light is on, the wiring is correct. If it is not lit, check if there is a wiring error.
